You can depend on the M5001 Series Standard Model tractors for outstanding performance and year-round comfort. The performance begins with a reliable and efficient Kubota engine that can power through even the toughest tasks with ease and speed. There’s plenty of power for PTO-driven implements,
as well as convenient electronic speed control to keep those implements operating at optimum efficiency. A fully synchronized transmission and an advanced hydraulic shuttle for shifting between forward and reverse simplifies tractor operations.
The comfort starts with a spacious all-glass cabin that offers excellent visibility out all sides and super-wide doors on both sides for easy entry and exit. Add a soft and comfy deluxe seat and ergonomically placed controls, and you’ll enjoy all- day comfort that lasts until the job is done.
The M5001 Series truly is the smart choice for all types of field work.
M5-1 NARROW 93-105HP
The Specialist
You can depend on the M5001 Series Narrow Model tractors for outstanding performance and year-round comfort. The performance begins with a reliable and efficient Kubota engine that can power through even the toughest tasks with ease and speed. There’s plenty of power for PTO-driven implements, as well as convenient electronic speed control to keep those implements operating at optimum efficiency. A fully synchronized transmission and an advanced hydraulic shuttle for shifting between forward and reverse simplifies tractor operations.
To work in the confines of orchards and vineyards, you need a special kind of tractor, one that’s narrow, with high ground clearance and excellent stability. The M5001N Series are just that kind of tractor. Just 48” wide, the M5001N Series can go where standard-width tractors can’t, letting you work with spreaders, sprayers, trimmers, leaf removers, and more in the tight spaces between rows of trees and vines. The ability to turn tightly from one row to the next ensures the productivity you expect.
Features
ENGINE
Performance- driven technology
The power behind the M5001 Series’ superior performance and efficiency comes from advanced Kubota-built diesel engines. These rugged engines also offer cleaner emissions, quieter operation, and greater fuel efficiency.
Constant RPM Management
The M5001 Series engines feature a new electronic governor that gives you electronic control of engine RPM. Activating the system keeps engine revolution constant, preventing drops in PTO speed and enabling stable operation. It makes working with PTO-driven implements much more efficient.
Improved torque and fuel consumption
The M5001 Series engines run at lower engine speeds without any loss of performance, thanks to improved torque and performance settings. Lower engine speeds also mean quieter operation, less engine wear, and greater fuel efficiency.
TRANSMISSION
In the right gear
Whatever the task, there’s a gear that will get it done. The M5001 Narrow Series offers 36 speeds — forward and reverse — with Dual Speed technology, ensuring that you are always working efficiently.
Fully synchronized transmission with single shift lever
A single shift lever makes shifting between gears smooth, simple, and direct. Whether you’re
traveling quickly between jobs or moving slowly in a specialty crop, the M5001 Series’ transmission offers the optimum gear for the task.
Over Drive
The Over Drive function keeps the engine revolutions at around 2000 rpm during high speed driving for better fuel economy.
Electro Hydraulic shuttle
An electro-hydraulic shuttle lever lets you quickly and easily change directions without using the clutch. Simply flick the lever forward or backward, and the M5001 Series tractor instantly changes direction, smoothly and without stopping. The lever is located on the left side of the steering wheel for easy access. Faster, simpler direction changes means improved productivity.
HYDRAULICS
Superior pump capacity
With hydraulics pump capacity of 69-litres per minute dedicated to linkage and remotes and with up to 5 remotes with mid-mount options, the M5 narrow will become the go-to tractor for the discerning viticultural and orchard operation.
Highly efficient PTO work
The independent PTO shaft runs at 540 rpm or 540 Eco rpm, letting you efficiently take on a wide range of tasks, from cutting grass to baling and spraying. The PTO shaft brake engages automatically whenever the PTO shaft is disengaged to safely stop implements.
The PTO shaft clutch can be engaged and disengaged electro-hydraulically while in operation, improving the efficiency of mowing and baling operations. The optional 1000 rpm retrofit kit adds another dimension to your tractor.
3-point linkage and hydraulic remotes
Strong enough to raise heavy implements, the M5001 Series’ rugged 3-point hitch also provides powerful lift capacity of 2300kg at link ends. External cylinders improve lift capacity and ensure easy maintenance.
Two standard auxiliary control valves can be supplemented with three additional hydraulic valves with flow control and mid-mount options.
NARROW CAB
Cabin
An all-glass cab and a newly designed bonnet ensure
excellent visibility in all directions, including both front
and rear implements as well as the immediate working environment. The cab glass is curved to reduce glare and enhance spaciousness, while narrow pillars and a sloping bonnet increase visibility in all directions.
Cab doors
Large doors on each side open wide for quick and easy entry and exit. Both doors are glass from top to bottom
for greater visibility of the area around the doors. When combined with the level platform, ergonomically positioned pedals, entry and exit are safe, convenient, and quick.
Tilt steering wheel
For easier entry and exit as well as optimum working comfort, the M5001N offers a tilt steering wheel and a flat platform. The angle of the steering wheel can be quickly adjusted with the press of a pedal. Tilt steering also provides greater forward visibility and a better view of the dashboard.
TRACTION
High ground clearance
A high front axle provides the clearance needed to pass over delicate crops, such as hay, that are easily damaged. A high ground clearance is also useful when working in row crops.
Bevel-gear front-wheel drive with bi-speed turning
The M5001N Series tractors turn smoothly and tightly. With Kubota’s exclusive Bi-speed Turn technology, whenever a turn exceeds an angel of about 30 degrees, the front wheels begin turning twice as quickly as the rear wheels, allowing you to safely and easily enter an adjacent crop row on the first attempt. Bi-speed turning automatically turns off when traveling at high speed.
Superior traction
The M5001 Series’ excellent traction lets you work even in challenging terrain conditions. Limited slip differentials on
the front and rear axels ensure a uniform travel speed even during turns or when one wheel is slipping. Superior traction also allows heavier loads to be towed and provides greater grip for loading operations. The rear differential can be locked when terrain conditions are particularly difficult.
Specifications
M5091
DTHNQ-DS
M5101
DTHNQ-DS
Engine
Engine type
V3800-CR-TIE4
Displacement/No. of cylinders (cm³)
3,769 / 4
Related speed rpm
2600
Engine power output (97/68/EC) – hp (kw)
93 (69)
105 (78)
Fuel tank capacity (L)
76
Transmission
Type – Main gear shift
6 speed synchronised
No. of speeds
F36/R36 with Dual speed
Max. travelling speed
(km/h)
35
Range gear shift
3 ranges (H-L-C)
Main gear shift
6 fully syncronised with Hi/Lo
Shuttle shift
Electro-hydraulic shuttle
Main clutch
Multiple wet disc, electro-hydraulically operated
Brake type
Hydraulic discs, 4 wheel braking
4WD engagement
Electro-hydraulic w/ Bi-speed
Front differential lock F/R
–
–
Rear differential lock F/R
Mechanical type
PTO
Speed (rpm)
540 / 540E; Option: 540 / 540E / 1,000
Hydraulics
Pump capacity (L/min)
68.6
3-point hitch
Category II
Control system
Mechanical (position, draft & mix)
Lift capacity at ball end (kg)
2300
No. of remote valves
2; max. 5 with integrated flow control
Standard tyre size
280/70R16 380/70R24
Dimensions & weight
Overall length (mm)
3750
Overall height (mm)
2335
Overall width (mm)
1432 – 1723
Wheelbase (mm)
2130
Tread width – front (mm)
1137-1161
Tread width – rear (mm)
1052-1343
Turning radius (w/o brake) m
3.8
Tractor weight (kg)
2600
M5-1 STANDARD
The Allrounder
You can depend on the M5001 Series Standard Model tractors for outstanding performance and year-round comfort. The performance begins with a reliable and efficient Kubota engine that can power through even the toughest tasks with ease and speed. There’s plenty of power for PTO-driven implements, as well as convenient electronic speed control to keep those implements operating at optimum efficiency. A fully synchronized transmission and an advanced hydraulic shuttle for shifting between forward and reverse simplifies tractor operations.
ENGINE
Performance- driven technology
The power behind the M5001 Series’ superior performance and efficiency comes from advanced Kubota-built diesel engines. These rugged engines also offer cleaner emissions, quieter operation, and greater fuel efficiency.
Constant RPM Management
The M5001 Series engines feature a new electronic governor that gives you electronic control of engine RPM. Activating the system keeps engine revolution constant, preventing drops in PTO speed and enabling stable operation. It makes working with PTO-driven implements much more efficient.
Improved torque and fuel consumption
The M5001 Series engines run at lower engine speeds without any loss of performance, thanks to improved torque and performance settings. Lower engine speeds also mean quieter operation, less engine wear, and greater fuel efficiency.
TRANSMISSION
In the right gear
Whatever the task, there’s a gear that will get it done. The M5001 Series offers— 18 forward and 18 reverse —from six synchronized gears in three ranges. Dual Speed technology in the leading models takes this to 36 forward and 36 reverse gears, ensuring that you are always working efficiently.
Fully synchronized transmission with single shift lever
A single shift lever makes shifting between gears smooth, simple, and direct. Whether you’re
traveling quickly between jobs or moving slowly in a vegetable plot, the M5001 Series’ transmission offers the optimum gear for the task.
Over Drive
The Over Drive function keeps the engine revolutions at around 2000 rpm during high speed driving for better fuel economy.
Electro Hydraulic shuttle
An electro-hydraulic shuttle lever lets you quickly and easily change directions without using the clutch. Simply flick the lever forward or backward, and the M5001 Series tractor instantly changes direction without first having to stop. The lever is located on the left side of the steering wheel for easy access. Faster, simpler direction changes means improved productivity, particularly when working with a front loader, which requires frequent back-and-forth movements.
HYDRAULICS
Position control/Draft control
The M5001 Series’ hitch control system provides separate control of both position and draft, ensuring optimal control when using ground engaging rear implements. Use position control to control the implements independently of the required tractive power.
Draft control automatically adjusts to different soil conditions to maintain constant traction. Position and draft control can also be used together in draft mix.
3-point linkage and hydraulic remotes
Strong enough to raise even heavy implements, the M5001 Series’s rugged 3-point hitch also provides powerful hydraulics that respond quickly to improve the efficiency of implement operations. External cylinders provide a lift capacity of 4100kg at link ends.
Two standard auxiliary control valves can be supplemented with an optional hydraulic valve with flow control.
Highly efficient PTO work
The independent PTO shaft runs at 540 rpm or 540 Eco rpm, letting you efficiently take on a wide range of tasks, from cutting grass to baling and spraying. The PTO shaft brake engages automatically whenever the PTO shaft is disengaged to safely stop implements.
The PTO clutch is engaged and disengaged electro-hydraulically, improving the efficiency of operating any PTO driven implement. A 1000 rpm PTO shaft is also available as an optional retrofit kit.
STANDARD CAB
Ultra Grand Cab II
An all-glass cab and a newly designed bonnet ensure
excellent visibility in all directions, including both front
and rear implements as well as the immediate working environment. The cab glass is curved to reduce glare and enhance spaciousness, while narrow pillars and a sloping bonnet increase visibility in all directions.
Skylight with sunshade
Standard on all M5001 series models, this large glass skylight provides more light in the cab as well as a view of a fully raised front loader or pallet fork. On blindingly bright days, he skylight’s retractable sunshade can be closed to keep the sun out and the operator cool.
Cab doors
Large doors on each side open wide for quick and easy entry and exit. Both doors are glass from top to bottom
for greater visibility of the area around the doors. When combined with the level platform, ergonomically positioned pedals, entry and exit are safe, convenient, and quick.
Work lights
High-performance work lights ensure excellent visibility, allowing the M5001 Series to work safely and efficiently at night.
TRACTION
High ground clearance
A high front axle provides the clearance needed to pass over delicate crops, such as hay, that are easily damaged. A high ground clearance is also useful when working in row crops.
Four-wheel drive
The M5001 Series switches from two-wheel to four-wheel drive at the touch of a button without the need to come to a complete stop. When the brake pedal is pressed, four-wheel drive is automatically engaged for better braking power. An LED indicator conveniently shows the drive status.
Superior traction
The M5001 Series’ excellent traction lets you work even in challenging terrain conditions. Limited slip differentials on
the front and rear axels ensure a uniform travel speed even during turns or when one wheel is slipping. Superior traction also allows heavier loads to be towed and provides greater grip for loading operations. The rear differential can be locked when terrain conditions are particularly difficult.
