STCL Rock Crusher for PTO tractors with fixed teeth rotor from 70 to 150 hp

The STCL is the entry level model in the rock crusher line. Its small dimensions and lower weight make it highly versatile. It is designed and built for agricultural soil reclamation in loose and superficial rock. Its small size makes it ideal for use in vineyards and orchards. The internal counter knives are adjustable and determine the size of the final product. The rear door is designed to doze the material as they leave the crushing chamber. A differential gear box system is available to align the machine with the tractor PTO when working on uneven terrain.

Fits Tractor

from 70 to 150 hp

Shredding Diameter

15 cm max

Working Depth

15 cm max

APPLICATIONS

• AGRICULTURE
• ROCK CRUSHING
• LAND CONVERSION AND RECLAMATION

STANDARD EQUIPMENT

• Hydraulic rear hood
• Inner anti wear clad plates FCP
• Enclosed machine body
• Inside lateral protection
• Dual Row Protection chains
• Flat pressed welded steel counter-blades
• Adjustable extended 3 point linkage
• Poly-Chain®  belts transmission
• Gearbox with freewheel.
• PTO shaft with cam clutch
• Possibility to choose Transmssion 540 / 1000 rpm (ST)
• Bolt-on rotor shafts (in forged steel)
• Penetration skids.

TEETH

DESIGNED TO BE INCOMPARABLE

Ideal for: peaty soil, low rock content Teeth STCL/3STANDARD Ideal for: hardwood trees, exposed stumps, bushes and branches Side scraper C/3/SS sxSTANDARD Ideal for: hardwood trees, exposed stumps, bushes and branches Side scraper C/3/SS dxSTANDARD Previous Next

OPTIONS

Extended 3 point linkage

Hydraulic top link

Grader blade (road kit)

Dozing Blades
